ESD Epoxy Coated Tweezers - Antimagnetic/Anti-acid SS - tips: surface mount devices, component handling and positioning, monolithic chip, capacitors. OAL: 120mm
For placing and soldering 1mm wide monolithic chip capacitors.
| Tips type | SMD |
|---|---|
| Curved / angled / bent tip | No |
| Reverse action | No |
| Serrated handle | No |
| Serrated inner side | No |
| ESD safe | Yes |
| Coating | ESD Epoxy Coated |
| Photo | Article | ESD safe | OAL product (mm - in) | Tips thickness A (mm - in) | Tips width B (mm - in) |
|---|---|---|---|---|---|
|
Tweezers 00-SA-EPOXY | Yes | 115 - 4,52 | 0,7 - 0,027 | 0,4 - 0,015 |
|
Tweezers 615-SA-EPOXY | Yes | 155 - 6,10 | 0,9 - 0,035 | 1,3 - 0,051 |
|
Tweezers 3-SA-EPOXY | Yes | 120 - 4,72 | 0,2 - 0,0078 | 0,3 - 0,0118 |
